F405 BLS 50A 55A 60A 30x30 4in1 ESC BLHeli_S drone FPV controller w/External Capacitor DSHOT300/600 3-6S LiPo iNAV Betaflight
Description:
STM32 F405 v2 Flight control
Controller：STM32F405Gyroscope：MPU-6500
Barometer：BMP280/SPL06-001/DPS310
OSD：AT4756E
Black box：16MB
Motor output：8CH
Universal serial port：5CH
Output power supply：5V/2.5A，9V/2A
USB interface type：Type-C
Weight：8g
Compatible firmware: INAV/Betaflight
Note:
1. Receiver support: SBUS, PWM, lBUS, CRSF, ELRS default transfer machine access serial UART2.
2.DJl O3/O4/VISTA sky terminal is supported.
Bls 50-60A 4in1 ESC
Continuous maximum current: 50A/55A/60A x 4.
Instantaneous maximum current: 55A/60A/65A.
Input voltage: 3-6s Lipo (11.1V~22.2V)
Output voltage: VBAT.
On-board galvanometer: support.
TVS protective diode: YES.
Supported firmware name: Bluejay/ BLHeli-s.
Factory default firmware: Bluejay H_H_50_48_v0.21.0
Weight: 11g.
Mounting hole position: 30.5mm x30.5mm(4mm hole diameter).
Electrical control protocol:DSHOT150/DSHOT300/DSHOT600/STANDARD/ONESHOT125/ONESHOT42/MULTISHOT/PWM.
Note:
1. Support flight control adjustment of electrical parameters, through BLheil adjustment software.
2. Dampsd Light technology, regenerative braking function make motor deceleration more sensitive and effective andcontrol more accurate.
3. The active continuous flow technology, so that the battery recycling power, extend the life time.
4. Electrically modulated onboard filter capacitors that suppress back electromotive force, stabilize battery voltageand protect precision components of flight control.
